Overhead Paging System Featuring 16 C5 4" 70 Volt Ceiling Speakers, RMA240BT 240W Rack Mount Bluetooth Mixer Amplifier & PTT1 Paging Microphone

$ 3,231.99
$ 2,733.99

Overhead Paging System
for Businesses

High-Quality Speakers, Bluetooth Mixer Amplifier & Durable Paging Microphone

This overhead paging system for businesses is designed to elevate the ambiance of your establishment. By integrating 16 top-of-the-line 4" 70-volt ceiling speakers with a powerful 240W Bluetooth mixer amplifier and a robust, user-friendly push-to-talk paging microphone, this system promises to redefine the audio experience within your space. This versatile paging system is designed to deliver exceptional sound quality and coverage, ensuring that your customers and guests enjoy a seamless and immersive environment.

Provide Clear
Intelligible Paging

for Business Facilities

RECESSED DESIGN

The C5's compact recessed design with an ultra-thin flat bezel offers a small footprint that seamlessly integrates into any ceiling while maintaining quality audio.

QUICK AND EASY TO INSTALL

The threaded screw-on Easy-Mounting ring ensures effortless installation in drop tile ceilings, while the included tile bridge offers additional support.



POWERFUL BLUETOOTH AMPLIFIER

You can connect your Bluetooth device to the RMA240BT's multimedia player and also use an SD card, USB thumb drive, or the built-in FM tuner.

WORKS LONG HOURS

The RMA240BT features a forced air-cooling fan, which helps accommodate the long working hours of any commercial facility applications.

EMERGENCY FEATURE

In the event of an emergency, you can quickly use the emergency input to stop all other audio transmissions. This input takes priority letting any integrated emergency voice alarm system be heard loud and clear.

PAGING & ANNOUNCEMENTS

The PTT1 push-to-talk tabletop microphone is ideal for paging and announcements in business applications.



OVERHEAD PAGING SYSTEM FOR BUSINESSES WITH BLUETOOTH

This overhead paging system is designed to enhance communication and the overall atmosphere within your commercial establishment. It combines 16 high-quality C5 4" 70-volt ceiling speakers with an RMA240BT 240W Bluetooth mixer amplifier and a durable, user-friendly PTT1 push-to-talk paging microphone. This overhead paging system for businesses can effectively cover areas such as waiting rooms, lobbies, hallways, and offices in your business.

EMERGENCY AUDIO CUT OFF

In the case of an emergency, you won't need to worry about turning off your audio or adjusting inputs or volume. The RMA240BT mixer amplifier includes an emergency input that will stop all other audio transmissions, allowing emergency voice alarm systems to be heard loud and clear throughout your venue so you can respond to emergencies efficiently and safely.

C5 Micro 4" 70 Volt Ceiling Speakers

The Pure Resonance Audio C5 is a compact 4" micro 70-volt ceiling mount speaker known for its seamless integration. It offers high-quality audio for music, paging, and sound masking in commercial spaces. The C5 maintains a 120° x 120° coverage of robust audio with superb vocal intelligibility and full-range music reproduction. The speaker features a 4" driver and a frequency response of 90Hz - 20kHz with 91dB sensitivity. It includes a built-in 70V/100V transformer with an 8-ohm bypass and is easy to install with the provided screw-on Easy-Mounting ring and C5-TB tile bridge for added support.

RMA240BT 240W RACK MOUNT MIXER AMPLIFIER

The Pure Resonance Audio RMA240BT 5-channel Bluetooth commercial rack mount mixer amplifier delivers 240 watts of high-performance Class D power. You can connect your Bluetooth device to the RMA240BT's and also use a TF card, USB thumb drive, or the built-in FM tuner. You can also connect a separate media player if you wanted to play CDs. The included remote control manages volume levels, play/pause, skip, and more, all from a distance. Its forced air-cooling fan ensures reliable performance during extended use.



Due to the possibilities of FM radio interference and the variables involved, it's not recommended to use FM radio as your primary input source.

PTT1 DESKTOP PUSH-TO-TALK GOOSENECK MICROPHONE

The Pure Resonance Audio PTT1 desktop push-to-talk microphone provides excellent performance and reliability, ideal for paging and announcements in your business facility. The PTT1 features a uni-directional dynamic gooseneck microphone, table-stand, dual momentary locking switch, 5-foot cable, and three-pin male XLR connector. The durable gooseneck and metal table-stand ensure the PTT1 push-to-talk paging microphone can withstand even the toughest daily use in tough environments.


C5 CEILING SPEAKER SPECIFICATIONS:

RMS Power Rating:  10 Watt

Frequency Response:  90Hz - 20kHz

Low Frequency (-10 dB):  120Hz - 20kHz

Impedance:  8 Ohms

Transformer Taps:  2.5W, 5W, 10W @ 70V
                                   5W, 10W, 20W @ 100V
                                   8 Ohm Bypass

Transducer:  Full-range 4" driver

Nominal Coverage Angle:  120° x 120°

180° Coverage Angle:  84 dB ±3 dB

140° Coverage Angle:  86 dB ±3 dB

Maximum SPL:  104 dB ±3 dB

Cutout Size:  6.25" (158.75 mm)

Easy-Mounting Ring (Dia):  7.46" (189.4 mm)

Mounting Depth:
5.24" (132.84 mm) without connector
5.51" (139.83 mm) with connector

Overall Dimensions (Dia x D):
6.7" (170.2 mm) x 5.32" (135 mm) without connector
6.7" (170.2 mm) x 5.55" (141 mm) with connector

Weight:  2.93 lbs (1.33 kg)

RMA240BT MIXER AMPLIFIER SPECIFICATIONS:

Rated Power Output: 240W

Speaker Outputs: 4 - 16Ω/70V

Frequency Response: 80 Hz - 16 kHz +/- 3 dB

S/N Ratio: MIC1, 2, 3: 66 dB; AUX1, 2: 85 dB

THD: 0.05%

Indicator: Power indicator

Cooling Mode: Forced fan with variable speed cooling with side entry airflow

Protection Mode: Overheat/Short-circuit

Relative Humidity: <95% (No condensation)

Voltage: 110 - 120V 60Hz

Power Consumption: 300W

Remote Control: IR remote control with (replaceable) CR2025 3V lithium battery

Dimensions (H x W x D): 1.73" (44 mm) x 19.05" (484 mm) x 11.61" (295 mm)

Weight: 11.50 lbs (5.22 kg)

PTT1 Push-To-Talk Microphone SPECIFICATIONS:

Polar Pattern: Uni-directional

Frequency Response: 80Hz - 12kHz

Impedance: 600Ω ± 30%

Sensitivity: -72 dB ± 3 dB

Connector: 3-pin male XLR

Housing: Die-Cast Zinc

Cable: 1.5M (approx. 5')

Dimensions: 6.38" (162 mm) x 4.8" (122 mm) x 14.49" (368 mm)

Weight (without cable): 1.87 lbs (0.85 kg)

Includes

(16) Pure Resonance Audio C5 Micro 4" 70 Volt Ceiling Mount Speakers
        (16) Pure Resonance Audio C5-TB Tile Bridges for C5 4" Ceiling Speakers
(1) Pure Resonance Audio RMA240BT 240W 5-Channel Bluetooth Rack Mount Mixer Amplifier
        (1) IR Remote Control
        (1) Power Cord
(1) Pure Resonance Audio PTT1 Desktop Push-to-Talk Gooseneck Microphone
(1) Prep Wire to Female XLR Patch Cable - 6ft
(1000ft) 18/2 Gauge Speaker Wire
